| 型號 | 匹數 | 壓縮機 | 蒸發-45℃ | 蒸發-40℃ | 蒸發-37℃ | 蒸發-35℃ | 蒸發-30℃ | ||||||
| 型號 | 數量 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | ||
| JX324TL | 24 | S4N-8.2 | 3 | 13.20 | 13.68 | 18.20 | 15.24 | 20.20 | 16.17 | 22.60 | 16.80 | 27.60 | 18.40 |
| JX336TL | 36 | S4G-12.2 | 3 | 20.60 | 20.67 | 26.90 | 23.04 | 31.60 | 24.45 | 33.68 | 25.33 | 41.00 | 27.60 |
| JX348TL | 48 | S6J-16.2 | 3 | 30.80 | 27.51 | 40.50 | 31.74 | 46.10 | 34.23 | 50.60 | 35.91 | 61.20 | 40.06 |
| JX360TL | 60 | S6H-20.2 | 3 | 36.40 | 31.89 | 46.30 | 36.78 | 53.40 | 39.69 | 58.40 | 41.61 | 71.60 | 46.50 |
| JX375TL | 75 | S6G-25.2 | 3 | 40.10 | 36.60 | 53.20 | 42.06 | 60.30 | 45.57 | 66.80 | 47.76 | 82.40 | 53.30 |
| JX480TL | 80 | S6H-20.2 | 4 | 46.20 | 42.52 | 61.50 | 49.04 | 71.00 | 52.92 | 77.50 | 55.48 | 95.60 | 61.90 |
| JX390TL | 90 | S6F-30.2 | 3 | 48.00 | 43.80 | 63.10 | 50.52 | 72.60 | 54.51 | 79.30 | 57.15 | 96.90 | 63.70 |
| JX4100TL | 100 | S6G-25.2 | 4 | 53.50 | 48.80 | 70.60 | 56.08 | 80.50 | 60.76 | 88.80 | 63.68 | 109.30 | 71.00 |
| JX4120TL | 120 | S6F-30.2 | 4 | 63.70 | 58.40 | 83.90 | 67.36 | 96.60 | 72.68 | 106.60 | 76.20 | 130.20 | 84.60 |
| JX5150TL | 150 | S6F-30.2 | 5 | 79.50 | 73.00 | 104.60 | 84.20 | 12.60 | 90.58 | 132.30 | 95.25 | 162.60 | 106.10 |
| JX6180TL | 180 | S6F-30.2 | 6 | 95.60 | 87.60 | 125.30 | 101.04 | 144.50 | 109.02 | 158.90 | 114.30 | 194.20 | 127.30 |
| 型號 | 機組對外管路尺寸 | 標準支管理球閥數量 | 外形尺寸 | 電子低液位報警 | 重量 | 電氣參數 | 機房通風量 | |||||||
| 排氣 | 供液 | 吸氣 | 排氣 | 供液 | 吸氣 | 長 | 寬 | 高 | 最大工作電流 | 保險絲電流 | m³/h | |||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | 有Y/無Y | kg | ||||
| JX324TL | 22 | 22 | 54 | 1 | 1 | 1 | 3500 | 1100 | 1750 | Y | 1300 | 36 | 45 | 2000 |
| JX336TL | 35 | 22 | 54 | 1 | 1 | 1 | 3500 | 1100 | 1750 | Y | 1700 | 56 | 70 | 3000 |
| JX348TL | 35 | 22 | 67 | 1 | 1 | 1 | 3500 | 1100 | 1750 | Y | 1900 | 79 | 99 | 4600 |
| JX360TL | 35 | 2×16 | 2×54 | 1 | 2 | 2 | 3500 | 1100 | 1750 | Y | 2000 | 92 | 115 | 5200 |
| JX375TL | 42 | 2×22 | 2×54 | 1 | 2 | 2 | 3500 | 1100 | 1750 | Y | 2000 | 106 | 133 | 6000 |
| JX480TL | 42 | 3×16 | 3×54 | 1 | 3 | 3 | 4200 | 1100 | 1750 | Y | 2300 | 122 | 153 | 7000 |
| JX390TL | 42 | 3×16 | 3×54 | 1 | 3 | 3 | 3500 | 1100 | 1750 | Y | 2100 | 128 | 160 | 7000 |
| JX4100TL | 54 | 3×22 | 3×54 | 1 | 3 | 3 | 4200 | 1100 | 1750 | Y | 2500 | 141 | 176 | 8000 |
| JX4120TL | 54 | 3×22 | 3×67 | 1 | 3 | 3 | 4200 | 1100 | 1750 | Y | 2500 | 170 | 213 | 9600 |
| JX5150TL | 54 | 4×22 | 4×67 | 1 | 4 | 4 | 4900 | 1200 | 1800 | Y | 3000 | 212 | 265 | 12000 |
| JX6180TL | 54 | 5×22 | 5×67 | 1 | 5 | 5 | 5600 | 1200 | 1800 | Y | 3500 | 255 | 319 | 14400 |
