| 型號 | 匹數 | 壓縮機 | 蒸發-15℃ | 蒸發-10℃ | 蒸發-5℃ | 蒸發-0℃ | 外形尺寸 | |||||||
| 型號 | 數量 | 制冷量 | 輸入 | 制冷量 | 輸入 | 制冷量 | 輸入 | 制冷量 | 輸入 | 長 | 寬 | 高 | ||
| JX2180XM | 180 | HSK7471-90 | 2 | 214 | 108.40 | 266.00 | 113.40 | 323.60 | 118.60 | 390.70 | 124.40 | 2800 | 1750 | 2100 |
| JX3240XM | 240 | HSK7461-80 | 3 | 282.3 | 143.10 | 350.00 | 149.70 | 427.50 | 156.60 | 516.20 | 164.10 | 3400 | 1750 | 2100 |
| JX3270XM | 270 | HSK7471-90 | 3 | 324.2 | 162.60 | 398.10 | 170.10 | 485.10 | 177.90 | 586.40 | 186.60 | 3400 | 1750 | 2100 |
| JX4320XM | 320 | HSK7461-80 | 4 | 376.3 | 190.80 | 466.80 | 199.60 | 569.00 | 208.80 | 688.60 | 218.80 | 4300 | 1750 | 2400 |
| JX4360XM | 360 | HSK7471-90 | 4 | 427 | 216.80 | 529.60 | 226.80 | 646.20 | 237.20 | 780.80 | 248.80 | 4300 | 1750 | 2400 |
| JX5400XM | 400 | HSK7461-80 | 5 | 470.66 | 238.50 | 582.90 | 249.50 | 714.20 | 261.00 | 859.60 | 273.50 | 5200 | 2000 | 2400 |
| JX5450XM | 450 | HSK7471-90 | 5 | 533.90 | 271.00 | 662.60 | 283.50 | 808.00 | 296.50 | 976.00 | 311.00 | 5200 | 2000 | 2400 |
| JX6480XM | 480 | HSK7461-80 | 6 | 566.20 | 286.20 | 699.20 | 299.40 | 854.60 | 313.20 | 1029.60 | 328.20 | 6100 | 2000 | 2400 |
| JX6540XM | 540 | HSK7471-90 | 6 | 641.60 | 325.20 | 795.60 | 340.20 | 970.10 | 355.80 | 1170.00 | 373.20 | 6100 | 2000 | 2400 |
| 型號 | 匹數 | 壓縮機數量 | 機組對外管路尺寸 | 機組對外管路尺寸 | 電氣參數 | 房間通風量 | |||||
| 排氣 | 吸氣 | 供液 | 排氣 | 吸氣 | 供液 | 最大工作電流A | 保險絲電流A | ||||
| JX2180XM | 180 | 2 | DN65 | DN100 | 54 | 1 | 2 | 2 | 407 | 427 | 16500 |
| JX3240XM | 240 | 3 | DN80 | DN125 | 54 | 1 | 2 | 2 | 470 | 490 | 22500 |
| JX3270XM | 270 | 3 | DN80 | DN150 | 54 | 1 | 2 | 2 | 543 | 563 | 24800 |
| JX4320XM | 320 | 4 | DN80 | DN125 | 54 | 1 | 3 | 3 | 588 | 608 | 29900 |
| JX4360XM | 360 | 4 | DN100 | DN125 | 54 | 1 | 3 | 3 | 679 | 699 | 33000 |
| JX5400XM | 400 | 5 | DN100 | DN125 | 54 | 1 | 4 | 4 | 706 | 726 | 37400 |
| JX5450XM | 450 | 5 | DN100 | DN125 | 54 | 1 | 4 | 4 | 815 | 835 | 41300 |
| JX6480XM | 480 | 6 | DN100 | DN125 | 54 | 1 | 4 | 4 | 823 | 843 | 44900 |
| JX6540XM | 540 | 6 | DN100 | DN150 | 54 | 1 | 4 | 4 | 951 | 971 | 49500 |
